AM-350 Stainless Steel Flat Bar AISI 633 UNS S35000 Bar
Description
AM-350 Stainless Steel Flat Bar AISI 633 UNS S35000 Bar is a heat treatable austenitic or martensitic alloy, depending on heat treatment. AM-350 Stainless Steel brings together the strength of heat treatable martensitic grades with the corrosion resistance of some of the chromium nickel austenitic grades. Generally used in applications under 1000 °F where a combination of strength and good corrosion resistance are required.
All of AM-350 Stainless Steel Flat Bar AISI 633 UNS S35000 Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
Products Details
| Chemical Composition (weight%) |
| C(％): 0.07 ~ 0.11 |
| Si (％): ≤ 0.50 |
| Mn (％): 0.50 ~ 1.25 |
| P(％):≤ 0.025 |
| S (％):≤ 0.010 |
| Cr (％): 16.0 ~ 17.0 |
| Ni (％): 0.45 ~ 5.00 |
| Mo (％): 2.50 ~ 3.20 |
| N (％): 0.07 ~ 0.13 |
| Mechanical Properties Under Final Heat Treatment |
Condition: annealing
TS, σb/MPa: ≤1380
YS, σ0.2/MPa: 585~620
E, δ(％): 8~12
A, ф(％): -
Form: plate,sheet,strip
Condition: H850
TS, σb/MPa: 1175
YS, σ0.2/MPa: 1030
E, δ(％): 2~8
A, ф(％): -
Form: plate,sheet,strip
Condition: H1000
TS, σb/MPa: 1140
YS, σ0.2/MPa: 1000
E, δ(％): 2~8
A, ф(％): - |
Applications:
| AM-350 Stainless Steel used most often in the Bellows, industrial cutters, knives and a variety of vales and gas turbine componets |
Equivalent Grade
AM-350, AISI 633, UNS S35000
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of AM-350, AISI 633, UNS S35000 and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
Product Tags:
|
|
